Choosing the correct Multi-unit

blank

Patient in his 50’s had some implants that were made a long time ago.
on his last checkup he had some hopeless teeth that we decided to extract.
After the bridge removal some teeth broke, Two teeth were saved and we prepared crowns for them.

blank

Due to lack of maxillary bone the implants that were placed are buccally inclined.
You can see in the photo the prosthetic parts that were chosen, four 1mm angled Multi-units, one straight and one angled 2mm Multi-units.

Slide blank blank V-Type blank blank blank D-Type

The v type has a smaller cone and the hex is inside the multiunit, which is more suitable when there is not enough interocclusal space and what give more zirconia thickness – which strengthens the crown.
The D-type has a larger cone and an angulated version which has the same sleeve.

blank
blank

Scan with intraoral scanner.

blank
blank

After the scan was preformed a temporary bridge on Multi-units was designed.

blank
blank
blank

This is the bridge we made.
The sleeves  that were used in the bridge:
The four middle sleeves are for the angled D-type Multi-units
One sleeve is 3mm V-type, 3mm were used because a smaller size sleeve decreasing the size of the buccal bulge.
On the other side a standard 4mm sleeve that is blue were used.

blank
blank
DMD Skvirsky Igor

DMD Skvirsky Igor

Head of leading clinic and R&D technical laboratory specialized on implantology and digital prosthodontics in Tel Aviv. Dentist with 30 years experience, in 1995 started working with screw retained restoration. Author of numerous patents and inventions.
